Controller for solar systems SK1168

11,551 ₴

Other

Sunday 11:55

Україна

Київ Get directions →

вул. Стеценка, 14/44

9 views

Published 4 days ago by Solar-Tech

11,551 ₴

In Other category

вул. Стеценка, 14/44, Київ, Україна

Get directions →

9 item views

Solar thermal controller – a mandatory control element for solar systems with forced circulation of the heat transfer fluid. It controls the process of heating the heat transfer fluid from the sun and monitors the condition of the heating system as a whole. The operation of the solar system is managed as follows – the controller receives data from temperature sensors installed at the outlet of the solar collector and in the storage tank, analyzes them, and controls the circulation pump, which allows optimal electricity consumption.

Technical specifications:

Dimensions, (mm)

188х138х45

Power supply, (V)

AC110 / AC220

Consumption, (W)

< 3

Temperature measurement accuracy, (°C)

-/+2

Collector temperature measurement range, (°C)

-10…220

Tank temperature measurement range, (°C)

0…+110

Maximum pump power, (W)

5 pcs < 200

Inputs

2 pcs pt1000, 5 pcs ntc10k, 1 pc RS485

Outputs (relays for pump, valve, heating element)

3.5 A

Operating temperatures, (°C)

-10 +50

Protection class

IP40

Functions of the SK series controllers:

-
Manual control

-
Password setting

-
Return to factory settings

-
"Output" function

-
Manual heating function

-
Temperature indication

-
Memory protection

-
Water protection (auto shutdown)

-
Protection against incorrect connection

-
Error indication

Detailed list of controller functions:

Controller

CK1168

Remote control capability (Internet network)

Number of schemes (software algorithms)

Setting the temperature difference for switching on and off the solar circulation pump

Additional heating control function

Time-based recirculation

Stagnation temperature setting

Maximum collector temperature setting

Collector low temperature protection

Collector freeze protection

Tank cooling function

Set max. temperature of tank 1

Set max. temperature of tank 2

Set max. temperature of tank 3

Maximum shut-off temperature (solid fuel boiler, return heating control, heat transfer between tanks)

Minimum switch-on temperature (solid fuel boiler, return heating control, heat transfer between tanks)

Maximum temperature during heat transfer

Minimum temperature during heat transfer

Temperature to switch on heat transfer from tank 1 to 2

Temperature to switch off heat transfer from tank 1 to 2

Temperature to switch on heat transfer from tank 2 to 1

Temperature to switch off heat transfer from tank 2 to 1

Setting units of temperature measurement (Celsius-Fahrenheit)

"Antilegionella" function (Prevents bacterial growth in the storage tank by briefly heating the entire volume of water)

Control of recirculation switch-on temperature

Control function for heating from a solid fuel boiler

Control of circulation pump speed

Standard temperature differential (for controlling circulation pump speed)

Increase of circulation pump speed

Control of second circulation pump speed

Standard temperature differential for second pump

Increase of second circulation pump speed

Measurement of collected thermal energy

Change of flow value

Selection of heat transfer fluid type

Change of heat transfer fluid concentration

Setting priority logic between tanks

Heating duration

Heating time interval

Bypass (high temperature)

Cooling of the storage tank (analog BYPA)

Delay function for activation of the circulation pump

Interval pump operation function (if there is no temperature sensor installed in the collector)

Activation time of INTV function

Deactivation time of INTV function

Time interval between circulation pump operations

Circulation pump operation time between checks

Temperature difference of the circulation circuit

Select type of connected flow meter

Record data to miniCD flash drive

Recording interval to card

Setting units of temperature measurement (analog C-F)

Thermostat function
